SEEPEX Progressive Cavity Pumps from John Brooks Company

SEEPEX progressive cavity pumps for use wherever low to highly viscous, aggressive or abrasive media must flow at low pulsation rates.  Call 1-877-624-5757 for more information.


Seepex Smart Conveying TechnologySeepex N Standard Pump RangeSeepex T Range Open Hopper Pumps
SMART CONVEYING TECHNOLOGY (SCT) STANDARD PUMPOPEN HOPPER PUMP
SCT means quick
maintenance; reduced
life cycle costs and
less maintenance
down-times.

CONVEYING CAPACITY
30 L/H – 500 M3/H
0.132 – 2,200  USGPM

PRESSURE UP TO
48 BAR – 720 PSI

CONVEYING CAPACITY

50 L/H – 500 M3/H
0.220 – 2,200  USGPM

PRESSURE UP TO
36 BAR – 540 PSI

Seepex D Range Metering PumpSeepex CS Range Food PumpSeepex M Range Macerator Pump
METERING PUMPFOOD PUMPMACERATOR

CONVEYING CAPACITY
0.2 L/H – 1000 L/H
0.053 – 264  USGPM

PRESSURE UP TO
24 BAR – 360 PSI

CONVEYING CAPACITY
30 L/H – 130 M3/H
0.132 – 572  USGPMPRESSURE UP TO
24 BAR – 360 PSI

FLOW RATE
2 M3/H – 150 M3/H
8.8 – 600  USGPM

Seepex E Range Semi-Submersible PumpSeepex W Range Wobble Pump
SEMI-SUBMERSIBLE PUMPWOBBLE PUMP

CONVEYING CAPACITY
30 L/H – 300 M3/H
0.132 – 1,320  USGPM

PRESSURE UP TO
12 BAR – 180 PSI

CONVEYING CAPACITY:
Up to 10 M3/H
44  USGPM

PRESSURE UP TO:
4 BAR – 60 PSI


What is a Progressive Cavity Pump

From Wikipedia, the free encyclopedia

A progressive cavity pump transfers fluid by means of the progress, through the pump, of a sequence of small, fixed shape, discrete cavities, as its rotor is turned. This leads to the volumetric flow rate being proportional to the rotation rate (bidirectionally) and to low levels of shearing being applied to the pumped fluid. Hence these pumps have application in fluid metering and pumping of viscous or shear-sensitive materials. The cavities taper down toward their ends and overlap with their neighbours, so that, in general, no flow pulsing is caused by the arrival of cavities at the outlet, other than that caused by compression of the fluid or pump components.

The progressive cavity pump  is a type of positive displacement pump and is also known as a progressing cavity pump, progg cavity pump, eccentric screw pump or cavity pump.

Read More


SEEPEX Progressive Cavity Pumps

Resources

Resource Download

SEEPEX Progressive Cavity Pumps

Size: 4 MB
Download
Resource Download

SEEPEX IQ Net Certificate

Size: 112 KB
Download
Resource Download

SEEPEX N - Standard Pumps

Size: 4 MB
Download
Resource Download

SEEPEX N - Standard Pump Dimensions

Size: 1 MB
Download
Resource Download

SEEPEX T - Open Hopper Pumps

Size: 388 KB
Download
Resource Download

SEEPEX D - Metering Pumps

Size: 326 KB
Download
Resource Download

SEEPEX CS - Food Pumps

Size: 312 KB
Download
Resource Download

SEEPEX - Macerator

Size: 258 KB
Download
Resource Download

SEEPEX E - Semi-Submersible Pumps

Size: 3 MB
Download
Resource Download

SEEPEX W - Wobble Pumps

Size: 588 KB
Download
SEEPEX

See All Products from SEEPEX
