SEEPEX T – OPEN HOPPER PUMPS

SEEPEX T Open Hopper Pumps handle viscous to semi-solid products with low or no flowability.

There are 9 models with multiple variations within each model and are suitable for nearly all industrial sectors.



SEEPEX T – FEATURES AND BENEFITS

  • Open hopper and auger feed screw design
  • Optimum product handling: open hopper and auger feed screw adjustable for each processing task
  • Easy maintenance due to quick access to the joints and plug-in connection




SEEPEX T – BTQ

csm spx prh btq

SEEPEX BTQ progressive cavity pumps have a wide square inlet and an identical footprint to the SEEPEX BN pumps.

SEEPEX BTQ FEATURES AND BENEFITS

  • For medium to highly viscous products with low flowability
  • Conveying capacity: 50 l/h – 100 m³/h (0.22 USGPM – 440 USGPM)
  • Pressure: up to 24 bar (360 PSI)
  • Compact design with directly flange-mounted drive (block type)
  • Square open hopper with 2-sided inspection port
  • Coupling rod with screw as a feeding aid
  • Available in free bare shaft design (TQNS range)
  • Better product handling due to the square inlet cross section and auger feed screw



SEEPEX T – BT

csm spx prh bt

SEEPEX BT progressive cavity pumps have a large rectangular open hopper with a compression zone and auger feed screw.

SEEPEX BT FEATURES AND BENEFITS

  • For highly viscous products with low flowability
  • Conveying capacities: 100 l/h – 300 m³/h (0.44 USGPM – 1,320 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Compact design with directly flange-mounted drive (block type)
  • Rectangular open hopper customized inlet dimension
  • Available with free bare shaft (TNS range)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone



SEEPEX T – BTM

csm spx prh btm 4ed911501a

SEEPEX BTM progressive cavity pumps have a patented, integrated macerating device in the compression zone which allows for easy processing in subsequent processes.

SEEPEX BTM FEATURES AND BENEFITS

  • For products with large pieces of fruits and vegetables
  • Conveying capacity: 0.25 m³/h – 130 m³/h (1.1 USGPM – 572 USGPM)
  • Pressure: up to 24 bar (360 PSI)
  • Extended compression casing with stationary cutting mechanisms
  • Rectangular open hopper, variable length
  • Extended auger feed screw with rotating knives in the compression zone
  • Compact design with directly flange-mounted drive (block type)
  • Available with free bare shaft (TMNS range)
  • Oxidation-free maceration of fruits and vegetables with subsequent conveying (pump installed in a closed system)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone
  • Simple dismantling of the compression casing



SEEPEX T – BTE

SEEPEX BTE progressive cavity pumps are designed with large rectangular open hoppers and an enlarged compression zone.

SEEPEX BTE FEATURES AND BENEFITS

  • For highly viscous and semi-solid products that tend not to bridge
  • Conveying capacity: 0.5 m³/h – 100 m³/h (2.2 USGPM – 440 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Rectangular open hopper, variable length
  • Compact design with directly flange-mounted drive (block type)
  • Auger feed screw with enlarged pitch and diameter
  • Available with free bare shaft (TENS range)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone with an enlarged cross section

SEEPEX T – BTI

csm spx prh bti 716a52d5d5

SEEPEX BTI progressive cavity pumps offer a rectangular hopper with an integrated and adjustable bridge breaker.

SEEPEX BTI FEATURES AND BENEFITS

  • For highly viscous to semi-solid products that tend to bridge
  • Conveying capacities: 100 l/h – 130 m³/h (0.44 USGPM – 572 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Rectangular open hopper, variable length
  • Bridge breaker with rotating paddle shafts and separate drive
  • Universal joint protection
  • Compact design with directly flange-mounted drive (block type)
  • Available with free bare shaft (TINS range)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone

Easy maintenance: compression casing can be dismantled

SEEPEX T – BTH

csm spx prh bth

SEEPEX BTH progressive cavity pumps combine various advantages from product group T. They feature a separately driven, centric running ribbon screw with a maximized diameter and variable pitch.

SEEPEX BTH FEATURES AND BENEFITS

  • For highly viscous, semi-solid and shear-sensitive products that tend to bridge
  • Conveying capacity: 0.5 m³/h – 130 m³/h (2.2 USGPM – 572 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Separately driven, centric and edge running ribbon screw with maximized diameter and sustained pitch
  • Separate adjustment of the conveying screw’s speed
  • Maximized, sustained pitch of the auger feed screw
  • Rectangular open hopper with vertical walls, length adjustable to the operating conditions
  • For almost all conveying products including ones that bridge (wide-open screw)
  • Ideal for all shear-sensitive media
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone

Easy maintenance: compression casing can be dismantled for service work



SEEPEX T – BTHE

csm spx prh bthe 14ce3763b3

SEEPEX BTHE progressive cavity pumps feature a large open hopper with vertical walls. The centric and edge running ribbon screw ensures an optimum product inflow to the pump’s conveying elements.

SEEPEX BTHE FEATURES AND BENEFITS

  • For highly viscous to semi-solid products that tend to bridge
  • Conveying capacity: 0.5 m³/h – 130 m³/h (2.2 USGPM – 572 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Centric and edge running ribbon screw
  • Maximized, sustained pitch of the auger feed screw
  • Rectangular open hopper with vertical walls, variable length
  • Compact design with directly flange-mounted drive (block type)
  • Available with free bare shaft (THES range)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone
  • Easy maintenance: compression casing can be dismantled for service work

SEEPEX T – BTES

csm spx prh btes 34d01dfa8b

SEEPEX BTES progressive cavity pumps have large hopper lengths and a shuttered closing system making them ideal for silo discharge systems. The pumps also ensure simple maintenance even when the silo is full.

SEEPEX BTES FEATURES AND BENEFITS

  • For highly viscous to semi-solid products from silo systems
  • Conveying capacity: 0.5 m³/h – 130 m³/h (2.2 USGPM – 572 USGPM)
  • Pressure: up to 24 bar (360 PSI)
  • Adjustable rectangular open hopper
  • Minimized overall height to avoid bridging
  • Compact design with directly flange-mounted drive (block type)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone with an enlarged cross section
  • Easy maintenance: compression casing can be dismantled for service work
  • Integrated sealing system to easily install/dismantle the conveying elements without draining the silo
  • Dismantling the conveying elements does not require additional space

SEEPEX T – BTEI

csm spx prh btei 471cf85d11

SEEPEX BTEI progressive cavity pumps are a further development of the BTI and BTE pumps. They have individually adjustable supply tanks, which replace additional storage in the system.

SEEPEX BTEI FEATURES AND BENEFITS

  • For highly viscous to semi-solid products that tend to bridge
  • Conveying capacity: 0.5 m³/h – 100 m³/h (2.2 USGPM – 440 USGPM)
  • Pressure: up to 36 bar (540 PSI)
  • Bridge breaker/mixing device with rotating paddle shaft and separate drive
  • Rectangular open hopper, length and height adjustable to operating conditions
  • Supply tank for intermediate storage of the medium
  • Universal joint protection
  • Compact design with directly flange-mounted drive (block type)
  • Optimum filling of the conveying elements through a cylindrical/conical compression zone
  • Easy maintenance: compression casing can be dismantled for service work

SEEPEX BTEX

csm spx prh btex d6a7437b3e

SEEPEX BTEX progressive cavity pumps with their robust design and reinforced components are used in extreme conveying applications in the agriculture and biogas industries.

SEEPEX BTEX FEATURES AND BENEFITS

  • Products commonly found in the agriculture and biogas industries
  • For extreme conveying applications in the agriculture and biogas industries
  • Conveying capacity: 20–80 m3/h (90–350 USGPM)
  • Pressure: up to 8 bar (120 psi)
  • Foreign solids are separated within the special hopper design
  • Robust components for harsh applications
  • Large cross sections
  • Large inspection openings allow for easy removal of any separated solids
  • The high volume feed auger promotes thorough mixing of solid and liquid fermentation products
  • Removable compression housing ensures quick and easy maintenance
