Gorman-Rupp VG Series Pumps

Gorman-Rupp VG Series Pumps

Gorman-Rupp VG Series – centrifugal pumps are engineered for maximum operating efficiency and minimal energy consumption when pumping clear liquids. The enclosed impeller design incorporates double curvature vanes for higher efficiency. The entrance of the volute casing has dynamic positioning vanes that direct the flow to the impeller for increased efficiency while reducing net positive suction head (NPSH). Impeller trims can provide maximum flexibility for your specific application.

Gorman-Rupp offers a range of efficient standard centrifugal pumps with few moving parts requiring minimal maintenance and service. These rugged pumps offer years of performance life. The Gorman-Rupp VG Series Pumps are standard centrifugal, end suction, high efficiency pumps for clean liquids.

Optional Accessories for the Gorman-Rupp VG Series:

Pumps can be supplied with optional suction strainer, hand primer or fitted with optional seals and gasketing suitable for pumping today’s alternative fuels or other petroleum like liquids.


Size: 1-1/4″ (31.25 mm)
1-1/2″ (37.5 mm)
2″ (50 mm)
2-1/2″ (62.5 mm)
3″ (75 mm)
4″ (100 mm)
5″ (125 mm)
6″ (150 mm)
8″ (200 mm)
10″ (250 mm)
Max Capacity: 4,800 GPM (303 lps)
Max Head: 450′ (137 m)
Max Solids: 1.38″ (35 mm)
Max Temperature: 160 F (71 C)
Materials of Construction:  Cast Iron
Ductile Iron







Gorman-Rupp VG Series Pumps
