BETE Reactionary Force Tank Cleaning Devices for Small Tanks
BETE produces a diverse selection of tank cleaning nozzles that are designed to clean and sanitize tanks, drums, totes, and other vessels with precision, specifically for the food, beverage, pharmaceutical, and chemical processing sectors. Their rotational spray devices are engineered to enhance your cleaning process, achieving faster cleaning while utilizing less water and solvents than traditional spray balls. This results in a decrease in effluent discharge, ultimately saving energy and resources.
Design Features of BETE HydroWhirl Mini SS Tank Cleaning Nozzles
- Clean small tanks and equipment up to 6 ft diameter
- Compact design for hygienic equipment cleaning, drum, barrel, and tote washing
- Made from FDA-compliant, 316L Stainless Steel material
- Fluid-driven, self-flushing
- Durable compact design
- Requires no maintenance
- Suitable for food applications
- PEEK slide-bearing for greater longevity
BETE HydroWhirl Mini SS Spray Characteristics
| Available Spray Angle |
Flow Rate Range |
| 360° |
3.64 to 9.27 gpm |
| Available Connection Types |
Materials |
- Tube: 3/4in
- Pipe: 3/8
- Connection Methods: Thread (NPT, Female), Clip-on
|
316L |
How Spray Pattern of BETE HydroWhirl Mini SS Nozzles is Achieved
- By utilizing a rotating head at the end of the spray assembly, the HydroWhirl® Mini nozzle directs cleaning water with forceful movement throughout all areas of a tank's walls.
- This motion generates a dynamic spray pattern that efficiently washes the tank in a quick and thorough manner through the use of impact and repetition.
BETE HydroWhirl Mini SS Video
Rotating Tank Cleaning Nozzles: BETE HydroWhirl Mini 316L Stainless Steel
