The Verderflex 'VF' range is built to handle difficult media such as slurry, sludge, suspensions, solid-laden and thickened, viscous fluids with the fluid being contained within a flexible hose. The working principle creates up to 9.5m suction lift, with self-priming capability and can dry run with no damage to the pump. The open hose flow path permits larger solids to be handled with a reversible action should any blockage occur.
Benefits
- Disaster Proof Hose Connection for Easy Maintenance
- Close Coupled Drive Design
- Rigid pump housing design for heat dissipation and strength
Models
|
VF 100 |
VF 125 |
|
|
|
|
|
| Maximum Flow |
55 m3/h
|
90 m3/h
|
| Maximum Discharge Pressure |
16 bar
|
16 bar
|
| Maximum Temperature |
80 °C
|
80 °C
|
| Maximum Particle Size |
25 mm
|
31.25 mm
|
| Maximum Suction Lift | 9.5 m wc | 9.5 m wc |
| Hose Material | NR. NBR. NBRF. CSM. EPDM | NR. NBR. NBRF |
| Download Datasheet | Click to Download | Click to Download |
