Compact - Reliable - Innovative
The Dura series of innovative hose pumps offers a highly compact and low-maintenance solution. Its unique design minimizes the footprint by up to 70% compared to traditional peristaltic pumps. This range excels in handling abrasive slurries, dry-running liquid feeds, shear-sensitive polymers, high-viscosity sludge, and precise dosing applications.
Benefits
- Up to 70% Less Floor Space
- Fast & Simple Hose Changes
- Long Product Life and Precise Dosing
- Maximum Performance and Optimum Cooling
- Air Gap Between the Pump Head & Motor
- The Rotor is Centrally Located Over the Bearing
- Smoother Running Leads to Longer Life
- Reduced Radial Forces Minimize Power Consumption
Models
|
DURA 5 |
DURA 7 |
DURA 10 |
DURA 15 |
DURA 25 |
DURA 35 |
|
 |
 |
 |
 |
 |
|
|
| Maximum Flow |
23 l/h
|
39 l/h
|
222 l/h
|
593 l/h
|
2387 l/h
|
5292 l/h |
| Maximum Discharge Pressure |
8 bar
|
8 bar
|
12 bar
|
12 bar
|
12 bar
|
16 bar |
| Maximum Temperature |
50 °C
|
50 °C
|
65 °C
|
65 °C
|
65 °C
|
65 °C |
| Maximum Particle Size |
1.25 mm
|
1.75 mm
|
2.5 mm
|
3.75 mm
|
6.25 mm
|
8.75 mm |
| Certificates |
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935 |
| Maximum Section Lift |
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
9.5 m wc |
| Download Datasheet | Click to Download | Click to Download | Click to Download | Click to Download | Click to Download |
|
DURA 45 |
DURA 55 |
DURA 60 |
DURA 65 |
DURA 80 |
|
 |
 |
 |
 |
 |
|
| Maximum Flow |
12240 l/h
|
15300 l/h
|
16500 l/h
|
33000 l/h
|
42000 l/h
|
| Maximum Discharge Pressure |
16 bar
|
16 bar
|
16 bar
|
16 bar
|
16 bar
|
| Maximum Temperature |
90 °C
|
90 °C
|
100 °C
|
100 °C
|
100 °C
|
| Maximum Particle Size |
11.25 mm
|
13.75 mm
|
15 mm
|
16.25 mm
|
20 mm
|
| Certificates |
Atex. FDA. EC/1935
|
Atex. FDA. EC/1935
|
ATEX
|
FDA. EC/1935
|
ATEX. FDA CFR21. EC/1935
|
| Maximum Section Lift |
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
9.5 m wc
|
| Download Datasheet | Click to Download | Click to Download | Click to Download | Click to Download | Click to Download |
