Plenty T-Type Simplex Strainers extend the range of S-Type filters to higher pressures, suitable for both liquid and gas applications and available with bolted or quick release type covers.
Standard Features
- Quick release covers eliminate the need for tools for maintenance.
- Designed for pressure ratings up to ANSI class 300lb (900 PSIG).
- Flow is from inside to outside the basket to trap and retain debris.
- High basket area to pipeline CSA ratio of over 10:1 in most cases.
- Can be fitted with coarse perforated baskets (2mm as standard) or fine stainless steel mesh inserts to give particle removal down to 50 microns.
- Disposable depth type cartridges are available for filtration to 5~10 micron for liquid and 1~2 micron on gases.
Plenty T-Type Simplex Filters
- Body material – stainless or cast steel or special alloys.
- Available with RTJ flange facing.
- Available complying with current Transco specifications.
- Can be supplied complying with BS5500 or ASME VIII design codes.
- Pleated baskets for high filtration areas.
- Reinforced baskets for withstanding high differential pressures.
- Magnetic element assemblies.
- Flanged connection for drain, vent and ancillary connections.
- Steam or hot water or hot water jackets.
- Supplied with ancillary equipment such as DP gauges and switches, air release heads, valves for vent and drains etc.
- 10″ and 12″ full ANSI class 300 rating.
- Sizes: 2″ to 12″ Bore flanged to ASME class 300RF, 600RF and 900RF. Can be drilled to BS tables and DIN standards.
