Wilden T1 Original Metal AODD Pumps

1/2″ | 13 mm

Wilden T1 Original Metal AODD Pump ensures reliability without sacrificing ease of maintenance. With simple installation and easy serviceability, it’s ready for rugged utilitarian applications that require a robust design.

Available wetted path materials are aluminum or stainless steel.

The Wilden T1 comes equipped with the Turbo-Flo™ Air Distribution System (ADS), which provides a durable, submersible and robust design, extensive installed base for proven technology and ease of maintenance.


Wilden T1 Original Metal Benefits and Features


The Successful Solution

  • Decades of proven performance
  • Intrinsically safe
  • Clamped connections for faster maintenance
  • Self-priming
  • Variable speed
  • Dry-run without damage
  • Single-point exhaust option
  • Shear-sensitive
  • Widest range of materials in the industry


Dependable

  • Longest Mean Time Between Repair (MTBR)
  • Proven air distribution systems (ADS)
  • Simplicity of design
  • Superior anti-freezing
  • Increased On/Off reliability


Economical

  • Low cost
  • Simple installation
  • Ease of maintenance


Wilden T1 Original Metal Performance


WETTED HOUSINGS

(Water Chambers and Manifolds)

Material Ship Wt
Aluminum 6 kg (13.0 lbs)

NON-WETTED HOUSINGS

Description Material
Center Section Nylon
Air Valve Brass, Teflon®-coated Brass, or Nickel-plated Brass


FLOW RATE

  • TO 54.9 LPM (14.5 GPM)

MAX PRESSURE

  • 8.6 BAR (125 PSI)

MAXIMUM SUCTION LIFT CAPABILITY

  • 1.52 m (5′) Dry, 9.45 m (31′) Wet

MAXIMUM DIAMETER SOLIDS

  • 1.6 mm (1/16”)

DISPLACEMENT PER STROKE

  • Rubber- 0.06 l (.017 gal.)
  • TPE- 0.06 l (.017 gal.)
  • PTFE- 0.05 l (.014 gal)


Elastomer Options

Material Temperature Limits
Buna-N -12.2 to +82.2 °C (+10 to +180 °F)
Polyurethane -12.2 to +65.6 °C (+10 to +150 °F)
PTFE +4.4 to +104.4 °C (+40 to +220 °F)
Saniflex™ -28.9 to +104.4 °C (+20 to +220 °F)
Viton® -40 to +176.7 °C (-40 to +350 °F)
Wil-Flex™ -40 to +107.2 °C (-40 to +225 °F)


Certifications

CE Mark (Conformité Européene – European Conformity)

CE

Wilden Pump & Engineering LLC has met the criteria for placing the CE mark on our product line. On December 3, 1999, Wilden fully self-certified its product line by meeting all the regulations of the Machinery and PED (Pressure Equipment) Directives. Every pump manufactured by Wilden will now receive the CE mark. Each pump box will also include a Safety Supplement manual in the eleven official languages of the European Community. This CE mark certification is indicative of Wilden’s pledge to providing our distributor network with all the sales tools necessary to excel in a global economy.

Wilden T1 Original Metal Pumps


Resources

Wilden T1 Original Clamped Metal Pump-EOM

Download
Size: 1 MB
