2″ | 51 mm
Wilden PS8 Stallion Metal AODD Pump is designed to transfer solid-laden slurries safely and effectively. Large internal clearances and flow-through design keep the pump from clogging while Wilden’s patented air distribution maintains ON/OFF reliability.
Stallion technology incorporates an altered ball/seat check valve assembly that maximizes part life, increases suction lift and maximizes flow rates.
The Wilden Stallion Series ensures reliability without sacrificing ease of maintenance. With simple installation and easy serviceability, it’s ready for rugged utilitarian applications that require a robust design.
Available wetted path materials are aluminum and ductile iron.
Wilden PS8 Stallion Metal AODD Pumps come equipped with the Pro-Flo SHIFT Air Distribution System (ADS) that provides 60% savings in air consumption, more yield per SCFM, precisely metered air consumption for less product waste and maximum Mean Time Between Repair (MTBR). Available Pro-Flo SHIFT center section material is aluminum.
Wilden PS8 Stallion Metal Benefits and Features
The Successful Solution
- Decades of proven performance
- Excellent for abrasive products and solid-laden slurries
- Intrinsically safe
- Clamped connections for faster maintenance
- Large internal clearance and flow-through design to prevent clogging
- ON/OFF reliability
- Unique ball/seat check valve assembly to maximize part life, suction lift and rates
- Ultra-Flex diaphragm technology increases parts life
- Polyurethane screen base for added durability
- Self-priming
- Variable speed
- Dry-run without damage
- Single-point exhaust option
- Shear-sensitive
- Widest range of materials in the industry
Dependable
- Longest Mean Time Between Repair (MTBR)
- Proven air distribution system (ADS)
- Simplicity of design
- Superior anti-freezing
- Increased On/Off reliability
Economical
- Greater flow per SCFM input
- Reduced air consumption and kilowatt usage
- Lower operational costs and downtime
- Optimized applications
Wilden PS8 Stallion Metal Performance
WETTED HOUSINGS
(Water Chambers and Manifolds)
| Material | Ship Wt |
|---|---|
| Aluminum | Aluminum |
| Ductile Iron | 49 kg (109 lbs) |
NON-WETTED HOUSINGS
| Description | Material |
|---|---|
| Center Section | Aluminum |
| Air Valve | Aluminum |
FLOW RATE
- TO 634 LPM (168 GPM)
MAX PRESSURE
- 8.6 BAR (125 PSI)
MAXIMUM SUCTION LIFT CAPABILITY
- 5.3 m (17.5’) Dry, 9.0 m (29.5’) Wet
MAXIMUM DIAMETER SOLIDS
- 19 mm (3/4”)
DISPLACEMENT PER STROKE
- TPE EZ-Install- 2.0 l (0.52 gal)
Elastomer Options
| Material | Temperature Limits |
|---|---|
| Geolast | -40 to +82 °C (-40 to +180 °F) |
| Polyurethane | -12 to +66 °C (+10 to +150 °F) |
| Saniflex | -28.9 to +104.4 °C (+20 to +220 °F) |
| Wil-Flex | -40 to +107.2 °C (-40 to +225 °F) |
Certifications
CE Mark (Conformité Européene – European Conformity)
Wilden Pump & Engineering LLC has met the criteria for placing the CE mark on our product line. On December 3, 1999, Wilden fully self-certified its product line by meeting all the regulations of the Machinery and PED (Pressure Equipment) Directives. Every pump manufactured by Wilden will now receive the CE mark. Each pump box will also include a Safety Supplement manual in the eleven official languages of the European Community. This CE mark certification is indicative of Wilden’s pledge to providing our distributor network with all the sales tools necessary to excel in a global economy.
ATEX (ATmosphere EXplosible)
It is only natural that the worldwide leading producer of air-operated double-diaphragm pumps complies with the ATEX 100A directive for explosive atmospheres. The European community and their safety are of the utmost importance to us. We take responsibility for not only our product, but also for the supporting documentation and compliance of necessary directives. Wilden is proud to introduce our metallic X pumps that comply with ATEX 94/9/EC Group I, category M2 and Group II, category 2 zones G & D. Our plastic X pumps comply with ATEX 94/9/EC Group II, category 2, zone G.
