Wilden A2 Original Plastic AODD Pumps

1″ | 25 mm

Wilden A2 Original Plastic AODD Pumps ensures reliability without sacrificing ease of maintenance. With simple installation and easy serviceability, it’s ready for rugged utilitarian applications that require a robust design.

Available wetted path materials are polypropylene or PVDF.

Wilden A2 Original Plastic AODD Pumps come equipped with the Accu-Flo™ Air Distribution System (ADS), which provides direct electrical interface control, reduced system costs, automated system operation and lube-free operation.


Wilden A2 Original Plastic Benefits and Features


The Successful Solution

  • Decades of proven performance
  • Intrinsically safe
  • Clamped connections for faster maintenance
  • Self-priming
  • Variable speed
  • Dry-run without damage
  • Single-point exhaust option
  • Shear-sensitive
  • Widest range of materials in the industry


Dependable

  • Longest Mean Time Between Repair (MTBR)
  • Proven air distribution systems (ADS)
  • Simplicity of design
  • Superior anti-freezing
  • Increased On/Off reliability


Economical

  • Low cost
  • Simple installation
  • Ease of maintenance


Wilden A2 Original Plastic Performance


WETTED HOUSINGS

(Water Chambers and Manifolds)

Material Ship Wt
Polyproylene 8.7 kg (19.0 lbs)
PVDF 10.1 kg (22.0 lbs)
NON-WETTED HOUSINGS
Description Material
Center Section Polypropylene
Air Valve Brass, Teflon®-coated Brass, or Nickel-plated Brass

FLOW RATE

  • TO 79.5 LPM (21 GPM)

MAXIMUM SUCTION LIFT CAPABILITY

  • 3.3 m (10.8′)

MAXIMUM DIAMETER SOLIDS

  • 3.17 mm (1/8”)

DISPLACEMENT PER STROKE

Model A2T

  • Rubber- 0.06 l (.015 gal.)
  • PTFE- 0.05 l (.014 gal)


DISPLACEMENT PER STROKE

Model A2P

  • Rubber- 0.12 l (.030 gal.)
  • PTFE- 0.11 l (.028 gal)


Elastomer Options

Material Temperature Limits
Buna-N -12.2 to +82.2 °C (+10 to +180 °F)
EPDM -51.1 to +137.8 °C (-60 to +280 °F)
Polyurethane -12.2 to +65.6 °C (+10 to +150 °F)
PTFE +4.4 to +104.4 °C (+40 to +220 °F)
Saniflex™ -28.9 to +104.4 °C (+20 to +220 °F)
Viton® -40 to +176.7 °C (-40 to +350 °F)
Wil-Flex™ -40 to +107.2 °C (-40 to +225 °F)


Certifications

CE Mark (Conformité Européene – European Conformity)

CE

Wilden Pump & Engineering LLC has met the criteria for placing the CE mark on our product line. On December 3, 1999, Wilden fully self-certified its product line by meeting all the regulations of the Machinery and PED (Pressure Equipment) Directives. Every pump manufactured by Wilden will now receive the CE mark. Each pump box will also include a Safety Supplement manual in the eleven official languages of the European Community. This CE mark certification is indicative of Wilden’s pledge to providing our distributor network with all the sales tools necessary to excel in a global economy.

Wilden A2 Original Plastic Pumps


Resources

Wilden A2 Original Clamped Plastic Pump-EOM

Download
Size: 1 MB
