EATON DCF 1600 Mechanically Cleaned Filters

EATON DCF 1600 Mechanically Cleaned Filters are ideal for highly viscous, abrasive, or sticky liquids. Eaton DCF 1600 mechanically cleaned filters operate at a consistently low differential pressure and deliver simple, reliable operation in which a low initial investment is a key driving factor.

EATON DCF 1600 Feature Comparison Chart

FEATURES DCF-400 DCF-800 DCF-1600
Single Unit Weight 35 lbs | 16 kg 75 lbs | 34 kg 215 lbs | 97.5 kg
Service Height 61.25 in | 1556 mm 69.25 in | 1760 mm 102 in | 2591 mm
Total Volumetric Capacity 0.94 gal | 3.5 liters 3.9 gal | 14.8 liters 11 gal | 41.6 liters
Purge Chamber Capacity 4 fl. oz | 119 ml 25 fl. oz | 0.74 liters 1.5 gal | 6 liters
Filtration Surface Area 112 in² | 722 cm² 264 in² | 1703 cm² 610 in² | 3935 cm²
Flow Rate Range at 100μ 2–20 gpm | 0.45–4.5 m3/hr 20–60 gpm | 4.5–13.6 m3/hr 60–200 gpm | 13.6–45.4 m3/hr
Maximum Temperature* 350˚ F | 177˚ C 350˚ F | 177˚ C 350˚ F | (177˚ C
Maximum Pressure 300 psi | 21 bar 150 psi (10.5 bar) standard 150 psi (10.5 bar) standard
Service Requirements
Minimum Air for Actuator Drive
60 psi at 5 cfm | 4 bar @ 8.5 m3/min 60 psi at 5 cfm | 4 bar @ 8.5 m3/min 80 psi at 5 cfm | 5 bar @ 8.5 m3/min
Electrical for Controllers Automated only Models – 110/220V, 50/60 Hz, single phase

* Dependent on elastomer seal selection.

Features of EATON DCF 1600 Mechanically Cleaned Filters

  • Automation Minimizes Disposable Waste and Labor Costs
  • Elimination or reduction in disposable filter bags and cartridges for reduced operator handling inventory costs and landfill waste
  • Reduction in product loss, more thorough contaminant purge in a highly concentrated waste stream
  • Virtually maintenance free, near 100% uptime
  • Compact design, lower capital cost to fit most installations
  • Stainless steel screens from 15 micron slots to 1/4″ perforations to handle a wide range of filtration needs
  • Available with UHMWPE, Urethane-, Teflon, or Kynar-Cleaning Discs

The DCF is the best self-cleaning filtration solution for minimizing product loss in high-value and/or high viscosity fluids.

When processing water and water-like liquids where a low initial investment is demanded, DCF single actuator models deliver tremendous benefits. Available in 400, 800, and 1600 sizes, The DCF-Series enables operation at a vast range of flow rates and retentions.

The DCF-800 and DCF-1600 are also available in twin actuator models, which are designed for the rigors of processing highly viscous, abrasive, sticky, or otherwise hard-to-process liquids. DCF Filters are suitable for a broad spectrum of challenging applications and accommodate a wide range of flow and retention requirements.

A unique circular cleaning disc design (MCF) ensures intimate contact with the screen to thoroughly and uniformly clean the media.

Markets Served:

  • Chemicals
  • Ethanol
  • Food and Beverage
  • Manufacturing
  • Oil and Gas
  • Pulp and Paper
  • PetroChem
  • Pharmaceuticals
  • Water

Typical Applications

  • Adhesives
  • Chocolate
  • CIP Fluids (Sodium Hydroxide)
  • Curtain Coaters
  • Detergents
  • Edible Oils
  • Ethanol Processing
  • Hot Fry Oils
  • Ink
  • Lime Slurries
  • Machining Coolants
  • Nutricuticals
  • PCC/GCC Slurries
  • Paint
  • Paper Coatings
  • Petroleum Based Greases
  • Phenolic Resins
  • Starch
  • Tallow
