Wilden GPS1 CSA-Certified Clamped Metal AODD Pump

Features and Benefits

Wilden® GPS Series pumps, equipped with the Pro-Flo® SHIFT Air Distribution System (ADS) and available in bolted metal construction, are certified by the Canadian Standards Association (CSA) to be powered by natural gas and maintain a safe, reliable operation. They are perfect for oil and gas operations where compressed air is not readily accessible but where natural gas is plentiful.

• GPS Series pumps utilize the Wilden Pro-Flo SHIFT ADS
  • Helps plants save valuable natural gas
  • Pro-Flo SHIFT uses 60% less natural gas, without hindering performance
  • Greater flow - more gallons pumped per SCFM

AIR INLET

• 1/2" FNPT

LIQUID INLET

• 13mm (1/2")

LIQUID DISCHARGE

• 13mm (1/2")

CONNECTION TYPE:

• NPT/BSPT (Threaded)

MAX SUCTION LIFT CAPABILITY:

• Rubber - 5.9 m (19.3') Dry, 9.8 m (32.3') Wet
• PTFE - 4.3 m (14.2') Dry, 9.7 m (31.7') Wet

MAX FLOW RATE

• Rubber – 60.2 lpm (15.9 gpm)
• PTFE – 59.8 lpm (15.8 gpm)

MAX PRESSURE

• 8.6 bar (125 psi)

MAX DIAMETER SOLIDS

• 1.6 mm (1/16”)

Displacement Per Stroke *

• Rubber – 0.10 L (0.026 gal)
• PTFE – 0.10 L (0.026 gal)

1 cycle = 2 strokes*

Elastomer Options
