The Pulsafeeder Blackline Pro leverages Pulsafeeder's established mechanical diaphragm pump technology, enhanced by the integration of a variable speed drive controller. Featuring ten customizable operating modes, the unit is ideal for advanced pumping processes requiring remote and automatic control. Available in various flow rates, pressures, and wet-end materials, the Blackline Pro offers tailored pumping solutions for diverse applications.
Crafted with a robust aluminum gearbox and control unit housing, coated with corrosion-resistant EPD, it stands as one of the most durable and purpose-driven metering pumps in the market. Emphasizing functionality, the metering pump boasts an angled back-lit display and a single jog dial element for versatile and user-friendly operation. For added convenience, the Blackline Pro is backward compatible, allowing it to be retrofitted onto existing Blackline pumps in the field via kit installation.
Pulsafeeder BLACKLINE Pro Features
- 10 operating modes to fit any application – Constant, Batch, Pause-Work, Proximity, Analog mA, Analog Volt, PPM, Pause-Percent, MLQ, Pulse
- Intuitive color coded display messages – Running, Warning and Alarm
- Variable gearbox orientation from 0 – 90degrees
- Backwards compatible possible installation on existing Blackline pump
- Aluminum casing with IP65/NEMA4X enclosure protection
- Ergonomical display clear and easy to read
- User friendly JDS – Jog-dial selector
Pulsafeeder BLACKLINE Pro Specifications
Pulsafeeder BLACKLINE Pro Accessories
- Back Pressure Valves
- Dampeners
- Pre-Engineered Systems
- Pulsation Dampeners
- Y Strainers Pressure Relief Valves
- Y-Strainers
Pulsafeeder BLACKLINE Pro Video Library
Pulsafeeder BLACKLINE Pro Introduction
Pulsafeeder BLACKLINE Pro Product Highlights
Pulsafeeder BLACKLINE Pro Overflow Alarm Settings
Pulsafeeder BLACKLINE Pro Remote Start Settings
Pulsafeeder BLACKLINE Pro Level Alarm Settings
Pulsafeeder BLACKLINE Pro Display Settings
Pulsafeeder BLACKLINE Pro Relay Output Settings
Pulsafeeder BLACKLINE Pro Analog Output Settings
Pulsafeeder BLACKLINE Pro Stats Settings
Pulsafeeder BLACKLINE Pro Firmware Settings
Pulsafeeder BLACKLINE Pro Proximity Settings
Pulsafeeder BLACKLINE Pro Unit of Measure Settings
Pulsafeeder BLACKLINE Pro Date and Clock Settings
Pulsafeeder BLACKLINE Pro Password Settings
Pulsafeeder BLACKLINE Pro Language Settings
Pulsafeeder BLACKLINE Pro Priming Settings
Pulsafeeder BLACKLINE Pro Pump Capacity Settings
Pulsafeeder BLACKLINE Pro Calibration Settings
Pulsafeeder BLACKLINE Pro Analog Pulse Working Mode
Pulsafeeder BLACKLINE Pro MLQ Working Mode
Pulsafeeder BLACKLINE Pro Percent Working Mode
Pulsafeeder BLACKLINE Pro PPM Working Mode
Pulsafeeder BLACKLINE Pro Analog Volt Working Mode
Pulsafeeder BLACKLINE Pro Analog mA Working Mode
Pulsafeeder BLACKLINE Pro Weekly Working Mode
Pulsafeeder BLACKLINE Pro Pause Work Working Mode
Pulsafeeder BLACKLINE Pro Batch Working Mode
Pulsafeeder BLACKLINE Pro Constant Working Mode
