3″ | 76 mm High-Pressure Saniflo Hygienic Bolted Metal Pump
Wilden H1500 High-Pressure Saniflo™ Hygienic™ Bolted Metal Pumps are uniquely designed for thick viscous product applications such as bean baste, peanut butter, and more. High-Pressure HS pumps meet high-cleanliness requirements and feature a free-draining flow path that enables them to be cleaned with ease. The HS flow-through liquid-path design also eliminates any potential areas where product residue can be trapped and contaminate the product. They are perfect for low-acid, pasteurized and protein-based products all the way up to bio-pharmaceutical sterile processes. HS pumps also meet the highest standards and requirements in the industry, including 3A, ATEX, EC 1935/2004, FDA CFR 21.177 and USP Class VI certification is available only for Saniflo HS pumps with PTFE elastomer options.
- Featuring energy efficient Pro-Flo® SHIFT ADS
- Free-draining flow path for CIP capability
- Easy assembly with self-centering ball cages
- Permanent or rotatable stand for cleaning
- Multiple valve options: ball, mushroom, or flap for different application requirements
- Shear sensitive
- Greater flow – more gallons pumped per SCFM
| AIR INLET: |
3/4″ FNPT |
CONNECTION TYPE:
|
Tri-Clamp® |
| DIN |
| SMS |
| MAX PRESSURE: |
85 psi (5.9 bar) |
VALVE OPTIONS:
|
Ball |
| Mushroom |
| LIQUID INLET: |
3″ (76mm) |
| LIQUID DISCHARGE: |
3″ (76mm) |
MAX FLOW RATE:
|
Integral Piston – Full-Stroke: 77 gpm (291 lpm) |
MAX DIAMETER SOLIDS:
|
1/4″ (6.4 mm) |
MAX SUCTION LIFT CAPABILITY:
|
Integral Piston – Full-Stroke: DRY – 12.5′ (3.8m) | WET – 29.5′ (9.0m) |
DISPLACEMENT PER STROKE (1 cycle = 2 strokes):
|
Integral Piston – Full-Stroke: 0.32 gal (1.2 L) |
Wetted Housings
|
|
Non-Wetted Housings
|
| MATERIAL |
SHIP WEIGHT |
|
DESCRIPTION |
MATERIAL |
| 316L Stainless Steel |
254 lbs (115 kg) |
Center Block |
Powder-Coated Aluminum |
| |
|
Air Valve |
Powder-Coated Aluminum |
| |
|
|
Air Chamber |
Stainless Steel |
Elastomer Options
| Material |
Temperature Limits |
| Wil-Flex™ |
-40°F to 225°F (-40°C to 107°C) |
