Wilden A.025 and A.025P Original Plastic AODD Pumps

¼” | 6 mm

Wilden A.025 and A.025P Original Plastic AODD Pumps ensure reliability without sacrificing ease of maintenance. With simple installation and easy serviceability, they are ready for rugged utilitarian applications that require a robust design.

Available wetted path materials are polypropylene, PVDF or carbon-filled acetal.

Wilden A.025 and A.025P Original Plastic AODD Pumps come equipped with the Pro-Flo® SHIFT Air Distribution System (ADS), which provides 60% savings in air consumption, more yield per SCFM, precisely metered air consumption for less product waste and maximum Mean Time Between Repair (MTBR).



Wilden A.025 and A.025P Original Plastic Benefits and Features



The Successful Solution

  • Decades of proven performance
  • Intrinsically safe
  • Self-priming
  • Variable speed
  • Dry-run without damage
  • Single-point exhaust option
  • Shear-sensitive
  • Widest range of materials in the industry



Dependable

  • Longest Mean Time Between Repair (MTBR)
  • Proven air distribution systems (ADS)
  • Simplicity of design
  • Superior anti-freezing
  • Increased On/Off reliability



Economical

  • Low cost
  • Simple installation
  • Ease of maintenance



Wilden A.025 and A.025P Original Plastic Performance



WETTED HOUSINGS

(Water Chambers and Manifolds)

Material Ship Wt
Polyproylene 1.4 kg (3.0 lbs)
PVDF 1.4 kg (3.0 lbs)
Carbon-filled Acetal 1.4 kg (3.0 lbs)

NON-WETTED HOUSINGS
Description Material
Center Section Polypropylene & Carbon-filled Acetal
Air Valve Aluminum



MAXIMUM SUCTION LIFT CAPABILITY

  • 3.53 m (11′)

DISPLACEMENT PER STROKE

A.025T

  • Rubber- 0.016 l (.004 gal.)
  • PTFE- 0.017 l (.005 gal)

A.025P

  • Rubber- 0.018 (.005 gal)
  • PTFE- 0.017 (.005 gal)



Elastomer Options

Material Temperature Limits
Buna-N -12.2 to +82.2 °C (+10 to +180 °F)
PTFE +4.4 to +104.4 °C (+40 to +220 °F)
Wil-Flex™ -40 to +107.2 °C (-40 to +225 °F)


Certifications

CE Mark (Conformité Européene – European Conformity)

Wilden-CE-Certification

Wilden Pump & Engineering LLC has met the criteria for placing the CE mark on our product line. On December 3, 1999, Wilden fully self-certified its product line by meeting all the regulations of the Machinery and PED (Pressure Equipment) Directives. Every pump manufactured by Wilden will now receive the CE mark. Each pump box will also include a Safety Supplement manual in the eleven official languages of the European Community. This CE mark certification is indicative of Wilden’s pledge to providing our distributor network with all the sales tools necessary to excel in a global economy.

Resources

Wilden A.025 Original Clamped Plastic Pump-EOM

Wilden A.025 Original Clamped Plastic Pump-EOM

Download
