VRC Valve Related Controls from John Brooks Company

VRC Valve Related Controls have been manufacturing quality American made products for over 30 years. There are hundreds of thousands of applications worldwide that have VRC units in their facilities providing solid trouble free service after 5-10-15 years and longer. In addition to being durable the VRC positioners are calibrated prior to shipment and due to the stable design generally never require any routine recalibration or service.

VRC Pneumatic & Electro-Pneumatic Valve Positioners

Download the Positioners Brochure

VRC Valve Related Controls Features

Modular:  Modularity is the cornerstone of the entire VRC line. Upgrading or modifying any unit is simple, quick and hassle-free. Switch from pneumatic to electro-pneumatic with ease. Upgrade a positioner in the field with Limit Switches and position Transmitters easily. VRC simplifies upgrades, minimizes inventory and eases servicing like no other line on the market.

Corrosion Resistant:  VRC corrosion resistance is unequaled. The I/P Converter and Position Feedback Transmitter are epoxy sealed and the Proximity Switches are hermetically sealed for the ultimate environmental protection. The PPA enclosure and internals exceed NEMA standards and are specifically designed for all routine and most highly corrosive applications. The PPA enclosure is inherently waterproof and carbon graphite filled to satisfy the toughest demands in both indoor and outdoor applications.

Easy to Mount:  Adaptability is a key feature of the V Series. Regardless of actuator model or design, the option V Series Universal Mounting Kit allows for customized adaptation to most current industry models, sizes and styles of quarter turn actuators. The low profile design of the V Series Universal Mounting Kit insures high performance adaption to the accessory side of the actuator.



VRC Construction Specifications

Part Materials
Models VI, VX, VF
  • Anodized and epoxy painted aluminum
Enclosure
  • PPA Composite
  • 300 Series Stainless Port Rings
  • Cover and Mounting Bolts
Indicator Lens
  • LEXAN
Internals
  • PPA
  • PPS and PEEK Composites
  • 300 Series Stainless Steel
  • Nickel Plated Brass
Spool Valve
  • Carpenter 70 Grade Stainless Steel
I/P Converter (VK02)
  • PPA Composite
  • TEFLON Coated Carbon Steel
  • Nickel Plated Carbon Steel
  • High Density Polyethylene DELRIN
Signal Diaphragm/O-Rings
  • BUNA N
VRC-VP-General-Purpose-Model-150x135

VP Model General Purpose Pneumatic Valve Positioners

The VP Model General Purpose Pneumatic Valve Positioners use a 3 – 15 psi input control signal to control valve or damper position. Many options are available to the basic unit to provide flexibility for your application. Positioner and options are designed for easy field installation. The base unit can be reconfigured to accommodate changes in your ongoing control needs, protecting your initial investment.

VRC-VE-Electro-Pneumatic-Valve-Positioners-150x135

VE Model General Purpose Electro-Pneumatic Valve Positioners

The VE Model Pneumatic Valve Positioner uses a 4 – 20 milliamp input control signal to control valve or damper position. Many options are available to the basic unit to provide flexibility for your application. Positioner and options are designed for easy field installation. The base unit can be reconfigured to accommodate changes in your ongoing control needs, protecting your initial investment.

VRC-VI-Electro-Pneumatic-Valve-Positioners-150x150

VI Model General Purpose + Hazardous Locations Electro-Pneumatic Valve Positioners

The VI Model Pneumatic Valve Positioner uses a 4 – 20 milliamp input control signal to control valve or damper position. Many options are available to the basic unit to provide flexibility for your application. The VI Model is designed for general purpose as well as hazardous locations.

Positioner and options are designed for easy field installation. The base unit can be reconfigured to accommodate changes in your ongoing control needs, protecting your initial investment.

VRC-VX-Electro-Pneumatic-Valve-Positioners-139x150

VX Model Hazardous Locations Electro-Pneumatic Valve Positioners

The VX model valve positioner incorporates a manifold mounted, 4 – 20 milliamp input, I/P that is approved for use in hazardous areas.

MODEL VX – Hazardous Locations Information

Note: For the VX model hazardous ratings apply to the I/P metal (NEMA 7) housing only, the positioner housing is NEMA 4x only

VRC-VF-Fail-Freeze-Electro-Pneumatic-Valve-Positioners-124x150

VF Model Fail-Freeze I/P Electro-Pneumatic Valve Positioners

The VF model valve positioner incorporates a manifold mounted, 4 – 20 milliamp input, I/P. The VF model can be used where you require the control valve to fail in position (Fail Freeze) on loss of the 4 – 20 milliamp input signal.

VRC-Valve-Positioner-Options

VRC Valve Related Controls – Pneumatic & Electro-Pneumatic Valve Positioner Options

VRC-Position-Indicator-Top-Cover-150x143

POSITION INDICATOR / TOP COVER

  • Flat 90°
  • Dome 90°
  • Flat 180°
  • Switch/Transmitter Mounting Cover
VRC-Characterizing-Cam-150x143

CHARACTERIZING CAM

  • Linear
  • Square Root
  • Square
  • 0-60 degrees
  • Equal Percent
  • Custom
  • Tangent
  • 0-45 degrees
  • 0-35 degrees

VRC-Spool-Valves-150x143

SPOOL VALVE

  • Standard Flow
  • Maximum Flow
  • Extreme Service Standard Flow
  • Extreme Service Maximum Flow
VRC-Port-Gauges-150x143

PORT GAUGES

  • Brass
  • Full Stainless
  • Stainless Cas
VRC-Position-Transmitters-150x143

POSITION TRANSMITTER

  • 4-20 MA
  • 1 k0hm
VRC-Limit-Switches-150x143

LIMIT SWITCH

  • Mechanical (2) SPDT
  • Proximity (2) SPST
VRC-Mounting-Brackets-150x143

MOUNTING OPTIONS

  • Brackets and couplers available to fit most actuators, to include linear applications.
VRC-Linear-Adaptions-Available-150x143

LINEAR ADAPTATIONS AVAILABLE

  • Stainless Steel Hardware

Resources

VRC Positioners Options Maintenace Manual

VRC Positioners Options Maintenace Manual

Download
VRC Positioners

VRC Positioners

Download
