Specifications
| Design Standard | API 609 BS 5155 EN 593 |
| Size Range | 1-1/2" - 72" |
| Pressure Rating | Class 150 PN10 PN16 |
| Working Temperature | -10˚C ~ +130˚C 14˚F ~ +266˚F (depends on seat materials) |
| End Connection | ANSI B16.1 ANSI B16.5 ASME B16.47 DIN 2501 BS 4505 |
| Face-to-Face | API 609 DIN 3202 EN 558-1 ISO 5752 |
| Test & Inspection | API 598 |
| Materials | Body : Ductile Iron | WCB | Stainless Steel Disc : Ductile Iron | AI-Bronze | Stainless Steel | Nylon | PTFE Seat : EPDM | NBR | Viton |
