Features
- High strength ductile iron body is used for reducing the weight and improving the valve's long-term durability.
- Simple mechanism with lever and float.
- The float and internal mechanism are made of SS304 for extended service life.
- All iron parts are coated inside & outside with fusion bonded epoxy for corrosion resistance as per AWWA C550.
- Male connection can easily be connected to isolated valves, no need for further nipples.
- End connection can be BSPT or NPT thread.
Specifications
| Size Range | 1/2” – 1” |
| Pressure Rating | 200 psi / 300 psi |
| Working Temperature | -10˚C ~ +80˚C 14˚F ~ +176˚F |
| End Connection | NPT Male |
| Materials | Body : Ductile Iron Seat : Rubber |
