Features
- Grooved connection compliant with AWWA C606 standard.
- Connection compatible with Victaulic Joints.
- High Strength ductile iron body used for lowering the weight and improving long term durability.
- All iron parts are coated inside and outside with fusion bonded epoxy for corrosion resistance as per AWWA C550.
- NSF61 approved material available as option.
Specifications
| Design Standard | AWWA C606 |
| Size Range | 2" - 12" |
| Pressure Rating | 300 psi |
| Working Temperature | -10˚C ~ +80˚C (14˚F ~ +112˚F) |
| End Connection | AWWA C606 |
| Materials | Body : Ductile Iron Disc : Ductile Iron Seat : EPDM |
