Pratissoli Series KF High Pressure Plunger Pumps
|
Construction Triplex high pressure plunger pump, four versions in one Symmetrical crankcase for easy “left to right” conversion Single P.T.O. shaft, d. 40 Plunger seal design: HP seal + LH seal with cooling chamber in low pressure Long life Suction/Delivery in line valves with spherical profile Splash lubrication |
Material quality Patent pending pump body in die-cast aluminium Nickel-treated stainless steel head Conical shaft bearings Aluminium alloy connecting rods Forged steel crankshaft Crankshaft sealings in viton Guide pistons in surface-treated cast iron Full ceramic plungers Stainless steel valves
|
| Pump Model | Volume | Pressure | Power | rpm | Weight Kg. | Dimensions mm. | |||
| L/min | GPM | bar | psi | kW | HP | ||||
| KF 28 | 93 | 24,5 | 210 | 3050 | 37 | 50 | 1000 | 69 | 526x367x253 |
| KF 30 | 106 | 28 | 200 | 2900 | 40 | 55 | 1000 | 69 | 526x367x253 |
| KF 32 | 120 | 31,7 | 180 | 2610 | 41,2 | 55 | 1000 | 69 | 526x367x253 |
| KF 36 | 153 | 40 | 130 | 1900 | 38,2 | 52 | 1000 | 69 | 526x367x253 |
| KF 40 | 170 | 45 | 110 | 1600 | 36 | 49 | 900 | 69 | 526x367x253 |
