E/One Sewer Systems from John Brooks Company

E/One Sewer Systems

The E/One Sewer system is a pressure sewer system that uses E/One grinder pumps. Grinder pumps are installed at each home, they collect the wastewater, and pump it to a larger sewer main or directly to a wastewater treatment plant.

These sewer systems are used in communities worldwide. They are an upgrade from existing pressure sewer systems, replacing septic tanks, or acting as an alternative to gravity sewer systems. E/One Sewer Systems offers a cost-effective alternative to gravity sewer systems because, unlike gravity systems, the low-pressure force mains follow the contour of the land.

E/One Sewer Systems from John Brooks Company are designed with high-quality grinder pumps that are reliable, efficient, and easy to maintain and come with a range of control and monitoring options to ensure proper operation. These systems are ideal for areas with rugged terrain or low population density and offer an economical and reliable alternative to conventional sewer systems. Due to their cost-effectiveness and easy installation, these sewer systems are an increasingly popular choice to improve wastewater to infrastructure within the municipal industry.

E/One Pressure Sewer Systems vs. Gravity Sewer Systems

Gravity sewer systems are the “original” central sewers, with origins in the Roman aqueducts. They must be accurately bedded along a continuous downward grade and often involve very deep trenches and large, costly lift stations.

How do E/One Pressure Sewer Systems Work?


Benefits of E/One Sewer Systems

  • Safe – protects water quality and enhances the quality of life
  • Reduces cost of housing, both initial and ongoing
  • Does not disrupt the beauty of the landscape or damage already-built structures
  • No preventive maintenance is required of the homeowner
  • Central sewers increase the value of homes



Upgrade an Existing Sewage Grinder Pump System

Replacement-Grinder-Pump-100x150If your community already has a pressure sewer system and needs to replace failing centrifugal grinder pumps, E/One has a solution. The E/One Upgrade is designed specifically for existing sewage grinder pump systems. The pump is engineered to fit into virtually any other wet well tank, allowing for easy drop-in installation. The best-in-class sewage grinder pumps for Canadian markets.






Frequently Asked Questions

Q: Who owns/maintains the grinder pump stations?

A: The grinder pump stations may be owned by the council/water authority (and the pressure pipe on private property) or by the homeowners individually. In the first instance, the municipality would maintain the sewage grinder pumps, and E/One’s local distributor would keep the municipality updated on training and product changes. If the homeowners own their grinder pump stations, they would be responsible for all installation and maintenance costs.

Q: What about backups? How can we be responsible for a homeowner who may continue to use water when a pump is down, creating a backup?

A: If the municipality owns the grinder pump stations, it is in the homeowner’s own best interest to alert the authority as soon as possible when the high-level alarm is audible. The education of the homeowner is critical. In an alarm condition, the homeowner should minimize water use within the home until repairs are completed.

Suppose the homeowners will be individually responsible for their grinder pump stations. In that case, it’s still a good idea to educate them about the grinder pump stations at the beginning of the project.



Grinder Pump Stations

E/One Sewer Systems – D-Series

The D-Series is E/One’s most popular product line. A range of station heights accommodates shallow to very deep burial requirements. Stations are available with one or two grinder pumps, depending on the tank chosen.

DH071-61x150 DH151-109x150 DH152-78x150

Model DH071

  • 1 Pump,
  • HDPE Tank,
  • 70 Gal Capacity,
  • 700 GPD

 Model DH151

  • 1 Pump,
  • HDPE Tank,
  • 150 Gal Capacity,
  • 1500 GPD

 Model DH152

  • 2 Pumps,
  • HDPE Tank,
  • 150 Gal Capacity,
  • 3000 GPD
DH272-84x150 DH502-108x150

Model DH272

  • 2 Pumps,
  • FRP Tank,
  • 270 Gal Capacity,
  • 5000 GPD
 Model DH502
  • 2 Pumps
  • FRP Tank,
  • 500 Gal Capacity,
  • 6000 GPD



E/One Sewer Systems – W-Series

The W-Series is E/One’s most flexible product line. A range of basins, covers, discharges, inlets and panels are available. Stations are available with up to four pumps, depending on the tank chosen.

Eone-Sewer-Systems-WH101-67x150 Eone-air-release-station-e1592257060953-74x150 WH231-150x109

Model WH101

  • 1 Pump,
  • HDPE Tank,
  • 100 Gal Capacity,
  • 700 GPD

 Model WH101F

  • 1 Pump,
  • HDPE Tank,
  • 100 Gal Capacity,
  • 700 GPD

 Model WH231

  • 1 Pump,
  • HDPE Tank,
  • 230 Gal Capacity,
  • 850 GPD
EOne-Sewer-Systems-WH471-150x109 EOne-Sewer-Systems-WH471-150x109-1 WH482_large-150x109

Model WH471

  • 1 Pump,
  • HDPE Tank,
  • 476 Gal Capacity,
  • 2000 GPD

Model WH472

  • 2 Pumps,
  • HDPE Tank,
  • 476 Gal Capacity,
  • 3500 GPD

Model WH482

  • 2 Pumps,
  • HDPE Tank,
  • 486 Gal Capacity,
  • 3500 GPD
WH482_large-150x109-1 WH482_large-150x109-2 Eone-W-Series-150x109

Model WH483

  • 3 Pumps,
  • HDPE Tank,
  • 486 Gal Capacity,
  • 5000 GPD

Model WH484

  • 4 Pumps,
  • HDPE Tank,
  • 486 Gal Capacity,
  • 7000 GPD

Model W Series Fiberglass

  • 1 to 4 Pumps,
  • Fiberglass Tank,
  • Various Capacities
  • Various GPD



Indoor Station

The IH091 is ideal for new construction where the sewage grinder pump station will be installed inside the home. The clean design looks at home with other appliances in the mechanical room.

Eone-Sewer-Systems-IH091-indoor-150x146

Model IH901

  • 1 Pump
  • HDPE Tank
  • 91 Gal Capacity
