Eaton BECO CARBON Depth Filter Sheets

Depth filter sheets of the Eaton BECO CARBON range have a high adsorptive capacity due to the use of immobilized activated carbon and are used for decolorization as well as for the removal of undesired by-products or for taste and odor correction.

The BECO CARBON activated carbon depth filter sheets offer a wide range of applications in the filtration of liquids in fine chemicals, pharmaceutical, cosmetics, food and beverage industries as well as in biotechnology.

Filter Material

Application

Compliance

Activated carbon Adsoptive filtration FDA, EC 1935/2004, BfR XXXVI/1

Core Features:

  • Due to the dust-free handling, the application is simple and clean.
  • Depth filter sheets with activated carbon types of different porosity meet the requirements of a broad range of applications.
  • In the BECO CARBON ACF 07.10 depth filter sheet filtration-active and adsorptive properties ideally combined.
  • The adsorption performance in the BECO CARBON ACF 02 and ACF 03 depth filter sheets is maximized through a carbon content of up to 1000 g/m² and the low endotoxin content ensures high product safety. A Validation Guide for BECO CARBON ACF 03 is available on request.

Industries:

  • Fine chemicals
  • Pharmaceutical
  • Biotechnology
  • Cosmetics
  • Food and beverage

Applications:

  • Decolorization and removal of organic impurities from active pharmaceutical ingredients (API) solutions:
    -         Decolorization of antibiotic solutions
    -         Protein and endotoxin removal
    -         Purification of blood plasma products
    -         Treatment of contrast media
  • Decolorization of natural extracts and cosmetics
  • Removal of unwanted by-products from food or dietary supplements, e.g., decolorization of glucose, enzyme and vitamin solutions
  • Correction of taste and color of beverages (spirits, fruit juices, hard seltzer etc.)
  • Decolorization and removal of organic impurities from chemicals, organic solvents and synthetic oils, e.g., removal of „off-flavor“ and unwanted by-products from silicone oils.

Models:

Product Model Number Description
Eaton-BECO-CARBON-ACF07-10-A 19602804 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 02, Dia. 47 mm
Eaton-BECO-CARBON-ACF07-10-A 19602806 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 02, Dia. 60 mm
Eaton-BECO-CARBON-ACF07-10-A 19602814 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 02, Dia. 140 mm
Eaton-BECO-CARBON-ACF07-10-A 19602822 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 02, Dia. 222 mm
Eaton-BECO-CARBON-ACF07-10-A 19603804 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 03, Dia. 47 mm
Eaton-BECO-CARBON-ACF07-10-A 19603806 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 03, Dia. 60 mm
Eaton-BECO-CARBON-ACF07-10-A 19603814 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 03, Dia. 140 mm
Eaton-BECO-CARBON-ACF07-10-A 19603822 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 03, Dia. 222 mm
Eaton-BECO-CARBON-ACF07-10-A 19607120 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, 200 x 200 mm
Eaton-BECO-CARBON-ACF07-10-A 19607140 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, 400 x 400 mm
Eaton-BECO-CARBON-ACF07-10-A 19607160 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, 600 x 615 mm
Eaton-BECO-CARBON-ACF07-10-A 19607804 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, Dia. 47 mm
Eaton-BECO-CARBON-ACF07-10-A 19607806 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, Dia. 60 mm
Eaton-BECO-CARBON-ACF07-10-A 19607814 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, Dia. 140 mm
Eaton-BECO-CARBON-ACF07-10-A 19607822 Eaton BECO CARBON Activated Carbon Depth Filter Sheet, ACF 07.10, Dia. 222 mm



Resources

Eaton BECO CARBON Filter Media Brochure

Eaton BECO CARBON Filter Media Brochure

Download
