Elevated Separators for Enhanced Solids Handling
________________________________________________________________________________________________________________________
This turnkey product is a complete separation and purging solution, combining a JPX separator with several purging and electrical control options. The PRX addresses the tough demands of the process industries, allowing for heavy solids loading with low-maintenance automatic purging options.
low Range: 4 – 12,750 U.S. GPM (1 – 2,895 m³/hr)
Maximum Pressure: 150 psi (10.3 bar)
- Fully-accessible LAKOS Separator
- Choice of inlet profile
- Automatic purging options
PRX System Specifications
| Models |
Flow Range |
Inlet/ Outlet Grooved Coupling* |
Purge Size Male NPT |
|
| US GPM | m3/hr | |||
| PRX-0004 | 4-10 | 1-2.5 | 1/2″ | 1″ |
| PRX-0010 | 10-20 | 2.5-4.5 | 3/4″ | 1″ |
| PRX-0016 | 16-30 | 4-7 | 1″ | 1″ |
| PRX-0028 | 28-45 | 7-10 | 1-1/4″ | 1-1/2″ |
| PRX-0038 | 38-65 | 9-15 | 1-1/2″ | 1-1/2″ |
| PRX-0060 | 60-100 | 14-23 | 2″ | 1-1/2″ |
| PRX-0085 | 85-145 | 19-33 | 2-1/2″ | 1-1/2″ |
| PRX-0130 | 130-225 | 30-51 | 3″ | 1-1/2″ |
| PRX-0200 | 200-325 | 45-74 | 4″ | 1-1/2″ |
| PRX-0285 | 285-525 | 65-120 | 4″ | 1-1/2″ |
| PRX-0450 | 450-825 | 102-187 | 6″ | 1-1/2″ |
| PRX-0650 | 650-1,200 | 150-275 | 6″ | 1-1/2″ |
| PRX-1160 | 1,160-2,150 | 265-490 | 8″ | 1-1/2″ |
| PRX-1850 | 1,850-3,400 | 420-775 | 10″ | 2″ |
| PRX-2650 | 2,650-4,900 | 600-1,115 | 12″ | 2″ |
| PRX-4200 | 4,200-7,800 | 950-1,775 | 16″ | 3″ |
| PRX-6700 | 6,700-12,750 | 1,520-2,895 | 20″ | 3″ |
PRX System Dimensions
| Models |
Dim A |
Dim B |
Dim C* | |||
| inches | mm | inches | mm | inches | mm | |
| PRX-0200 | 40″ | 1,016 | 67″ | 1,702 | 115-1/4″ | 2,927 |
| PRX-0285 | 51″ | 1,295 | 67″ | 1,702 | 121-3/4″ | 3,092 |
| PRX-0450 | 65-3/8″ | 1,661 | 67″ | 1,702 | 130-1/2″ | 3,315 |
| PRX-1160 | 74-7/8″ | 1,902 | 67″ | 1,702 | 143″ | 3,632 |
| PRX-0450 | 89-1/2″ | 2,773 | 67″ | 1,702 | 162-5/8″ | 4,131 |
*Add 13-1/4″ (337 mm) to overall height for systems with Purge Liquid Concentrator option.
