BETE Hydrowhirl Orbitor 100 (HWO100) Compact Tank Cleaning Machines

Rotary Jet High-Impact Tank Cleaning Devices

_____________________________________________________________________________________________________________



•  High impact jets for high-efficiency cleaning
• Orbital wash pattern rotates on 2-axis points
• Designed to meet hygienic standards; external surface finish: 0.5 microns Ra or better
• Self-cleaning; self-lubricating
• Easily repair on-site
• Designed with minimum moving parts to ensure extended operating life and reduced downtime
• Compact design fits through small access flanges and vessel openings
• Four nozzle configurations
• Available with ATEX approval

Rotary jets use the spray media flowing through internal gears on the body to rotate sets of high-impact jet nozzles through an efficient 2-axis orbital pattern, providing complete 360° coverage. The jet pattern nozzles utilized on these assemblies provide significantly more impact and impingement force than other styles of tank cleaning nozzles, making them ideal for hard-to-clean residues and larger vessels.
