Tuthill 1000 Series Lubrication Pumps

Tuthill 1000 Series Lubrication Pumps

Tuthill 1000 Series lubrication pumps are based on the proven internal gear principal, but have been enhanced in response to demands from our OEM customers for a pump that offers advanced features which make installation easier. These side-ported pumps have the option to bolt SAE/DIN flanges onto them ensuring maximum flexibility on the porting arrangements. Tuthill’s goal was to design a pump that meets your technical requirements and is easily fitted into your system.

Tuthill’s manufacturing expertise and knowledge of applications enable them to not only provide you with an engineered solution, but to ensure your satisfaction with post-sales service. Tuthill prides itself  on properly servicing you with specification, installation, operation and troubleshooting. The pump was originally designed to meet and exceed the exacting requirements of the refrigeration compressor market. The design has so many inherent features and benefits that our traditional customers are also seeing the advantages. The excellent performance of the 1000 series pumps are solving problems in many industries and varying applications. Contact us to review your application and determine if the 1000 series pump is your engineered solution.

Features of the Tuthill 1000 Series Lubrication Pumps:

  • Materials of construction: Body: EN/GJL/250, Rotor: Carbon Steel, Idler Gear: Sintered metal or steel
  • Self Priming
  • Non-pulsating flow
  • Mechanical seal fitted as standard (lipseal option only on direct mounted pumps)
  • Choice of ball bearing or carbon bearings in body: Carbon Bush, Idler is standard
  • Max speed: 1008-1010 3600 rpm, 1012-1024 1750 rpm
  • Max differential pressure 18 bar* (265psi)
  • Max inlet pressure 45 bar** (380psi)
  • Max temperature 200ºC (390ºF)

* For higher pressure consult us.

** Dependent on type of mechanical seal fitted.
