John Brooks Reverse Osmosis Systems are engineered to provide purified water that is up to 99.5% free of total dissolved solids (TDS) when configured in a double pass system. These highly reliable and economical units are available in pre-engineered sizes producing from up to 1,440 to 320,000 gallons per day of purified water. They are designed to meet the high-performance demands of a variety of industrial applications.
Standard components on our RO systems include 5-micron prefiltration at the inlet to protect the downstream components from resin fines and minor turbidity. Stainless steel centrifugal booster pumps provide the correct raw water pressure and flow rate to the Thin Film Composite (TFC) membrane(s). Process parameters such as flow, pressure, and treated water quality are measured and displayed on the integral instrumentation display rack and fully customizable control panel.
All of our Reverse Osmosis components are pre-piped, prewired, tested and shipped as a complete skid mounted package ready for installation with minimum floor space requirements. Our network of technically trained field personnel ensures that you receive immediate and reliable support and service 24 hours per day, 7 days per week.
Optional components are added to the units to allow for modifications to comply with virtually any engineering specification. Only high-quality, industry recognized components are utilized to ensure many years of maintenance free operation.
Standard Features:
- Low Energy Thin Film Composite Membranes FRP Reinforced Housings, up to 1,000 PSI for Sea Water Applications
- Polyurethane Coated or SS Frames
- Low-Pressure Protection for no Flow Situations
- Automatic Feed, Reject, Permeate and Flush Valves
- 5 Micron Prefiltration
- Water Quality Monitoring of Feed and Permeate Critical Parameters
- Feed, Concentrate and Recycle Control Valves
- Product, Concentrate and Recycle Flow Meters
- Glycerin Filled Pressure Gauges
- Multi-Stage Centrifugal Pump with TEFC Motor
- NEMA 4, UL Listed Control Panel includes Fully Programmable Process Controller, Control Switches, Lights, and Relays
- Power Supply: 208-230/1/60, 208-230/3/60, 575/3/60
- In Situ Cleaning Connections
