Pratissoli Series KS Triplex Plunger Pumps

Pratissoli Series KS Triplex Plunger Pumps



Construction

Triplex plunger pump, available in 4 versions. Patent pending, symetrical power end design featuring top and bottom mounting holes allowing for easy left to right shaft conversion. Lowhigh pressure packing design with integrated cooling system. high volumetric efficiency suction/delivery valves featuring new spherical design of sealing areas. Splash lubrication. External gearbox available in 3 ratios and positionable on left or right side of the pump. Flushing systems available on request on selected versions.



Material quality

High resistance light alloy crankcase. Stainless steel manifold, nickel treated. Tapered roller rim bearings Special antifriction light alloy conrods. Forged alloy steel crankshaft, hardened, tempered and nitrited. Cast iron piston guide, nickel treated. Solid ceramic plungers. Stainless steel valves.

Pump Model Volume Pressure Power rpm Weight Kg. Dimensions mm.
L/min GPM bar psi kW HP
KS 28 110 29,1 250 3650 52,5 72 1800 95 582x483x261
KS 28 110 29,1 250 3650 52,5 72 2200 95 582x483x261
KS 28 110 29,1 250 3650 52,5 72 1500 95 582x483x261
KS 32 145 38,3 200 3900 55 75 1500 95 582x483x261
KS 32 145 38,3 200 2900 55 75 1800 95 582x483x261
KS 32 145 38,3 200 2900 55 75 2200 95 582x483x261
KS 36 183 48,3 160 2350 56 76 2200 95 582x483x261
KS 36 183 48,3 160 2350 56 76 1500 95 582x483x261
KS 36 183 48,3 160 2350 56 76 1800 95 582x483x261
KS 40 226 59,7 138 2000 59,5 81 2200 95 582x483x261
KS 40 226 59,7 138 2000 59,5 81 1800 95 582x483x261
KS 40 226 59,7 138 2000 59,5 81 1500 95 582x483x261
KS 40I 240 63,4 140 2030 64 87 1950 95 582x483x261
KS 40I 240 63,4 140 2030 64 87 2390 95 582x483x261
KS 40I 240 63,4 140 2030 64 87 1650 95 582x483x261
